The Air Force Research Laboratory is immersed in early work on a new generation of hypersonic weapons designed to come after the currently emerging arsenal, expanding hypersonic mission options in new directions and introducing new air vehicle configurations.
The Pentagon and military services have been massively fast-tracking hypersonic weapons development, given the far-reaching warfare implications associated with firing weapons able to travel at five-times the speed of sound; numerous programs have been underway, and the most current estimation is that an initial set of hypersonic weapons will be operational by the early 2020s. Earlier this year, the Air Force conducted its first prototype hypersonic missile flight test; the service launched a sensor-only prototype of the AGM-183A Air-Launched Rapid Response Weapon from a B-52.
The advantages of these weapons are both self-evident and multi-faceted; they include much greater stand-off ranges for attack as well as a vastly increased ability to defeat, circumvent or even destroy enemy defenses. Hypersonic attack naturally reduces any kind of response time afforded to an enemy, possibly hitting or disabling a target before an enemy has a chance to respond.
The Pentagon and military services are already having some success with accelerated hypersonic weapons testing and development, yet there is still much work to be done when it comes to refining the technology needed for current and future hypersonic weapons flight. Engineering weapons to move at five times the speed of sound relies upon an ability to manage, and in effect minimize, the heat of the weapons. Excessive heat at that speed can not only incinerate the weapon such that it cannot fly but can also disrupt or derail its flight trajectory.
Therefore, the fundamental challenge with hypersonic flight resides in this need to manage the extreme temperatures reached at those speeds, factors which can prevent, complicate or disable successful hypersonic flight. An area of focus within this sphere of inquiry, AFRL developers tell warrior, relates to several complex aerodynamic challenges, such as managing the airflow surrounding the vehicle in flight. Referred to by scientists as a “boundary layer,” the airflow characteristics of a hypersonic weapon’s flight trajectory greatly impact the stability of the system - much of which relates to temperature.
“We are working on boundary layer phenomenology to better understand heat flux on hypersonic weapons. This will allow us to do optimization on thermal management,” Tim Sakulich, Air Force Research Lab, Director of Materials and Manufacturing and Lead on Implementing the Air Force S&T Strategy, told Warrior in an interview. “We are designing these systems to provide the speed, reach and lethality we are looking for.”
The science of airflow boundary layers is extremely complex, yet it does align with several key aerodynamic concepts related to hypersonic flight stability. Simply put, engineers are looking to create advanced hypersonic weapons that generate a “laminar” or smooth air-flow boundary layer, as opposed to a “turbulent” air-flow. The more movement, mixing or agitation in the airflow surrounding the air vehicle in flight, often consisting of movement or particle collisions in the airflow, the more turbulent it becomes, according to an essay from the University of Sydney’s School of Aerospace, Mechanical & Mechatronic Engineering. (Australia).
“A boundary layer may be laminar or turbulent. A laminar boundary is one where the flow takes place in layers ... each layer slides past the adjacent layers. This is in contrast to turbulent boundary layers, where there is intense agitation,” the 2005 essay states.
Of particular significance, the essay explains that turbulent boundary layers generate very high “heat transfer rates.”
“Packets of fluid may be seen moving across. (in turbulent boundary layers) Thus there is an exchange of mass, momentum and energy on a much bigger scale compared to a laminar boundary layer,” the Univ. of Sydney essay states.
In summary, as opposed to microscopic exchanges in mass known to occur in laminar boundary layers, turbulent boundary layers involve mixing across layers on a macroscopic level, the paper explains.
All of this leads to a current area of focus for scientists, who are experimenting with more ways to ensure laminar air-flow boundaries surround hypersonic flight vehicles. Laminar boundary layers are needed to advance hypersonic flight to a new generation, according to a significant paper from NASA, the AFRL and Case Western Reserve University called “Recommendation for Hypersonic Boundary Layer Transition Flight Testing.”
“In regards to a next-generation hypersonic vehicle, the design goal would be to maintain a laminar boundary layer for as long as possible in order to minimize heating. Small perturbations to the boundary layer can excite various instability modes,” the essay states. (NASA Langley Research Center, Air Force Research Laboratory, Case Western Reserve University… Scott Berry, Roger Kimmel, Eli Reshotko)
Increased heat can bring challenges; it strengthens the weapon's thermal signature, making it easier for sensors to track. Heat challenges can also introduce difficulties by creating a need to engineer a weapon able to withstand the heat levels and remain intact during high-speed flight. For this reason, hypersonic weapons -- and ICBMs as well -- are constructed with specially engineered heat-resistant materials. Sakulich emphasized that current AFRL work is, along these lines, focused on finding newer composite materials.
Improving hypersonic propulsion will not only improve the effectiveness and resiliency of existing weapons but also enable different form factors such as larger, longer or differently shaped attack weapons. The NASA-AFRL-Case Western essay, for instance, introduces the additional technical complexity that might be needed to advance hypersonic flight stability for “re-entry” bodies, such as those used on a nuclear-armed missile.
“Generally, the application of this knowledge (boundary layer management) has been restricted to simple shapes like plates, cones and spherical bodies. However, flight reentry vehicles are in reality never simple,” the NASA, AFRL essay states.
For example, rougher surface material or weapons vehicles with less linear configurations present additional complicating variables believed to impact the stability of hypersonic flight. Engineering scientific methods for increasing the laminar boundary layer properties of hypersonic vehicles, it seems apparent, could help lay a foundation for newer, next-generation hypersonic configurations, such as differently shaped drones or weapons with various warheads.
An interesting RAND essay, called “Hindering the Spread of a New Class of Weapons,” explains that heat signatures are impacted by the shape, size, velocity and trajectory of a weapon.
“The larger the nose radius, the smaller the heat transfer on the nose of the vehicle. Trajectory shaping, i.e., velocity and altitude, can also be used to manage the total heat transfer on an RV (Re-entry Vehicle) while meeting other input requirements and constraints, e.g.,range, maximum deceleration, and time of flight. Hypersonic weapons have different constraints and requirements compared with reentry bodies. HGVs(Hypersonic Glide Vehicles) and HCMs(Hypersonic Cruise Missiles) will tend to have sharp leading edges, i.e.,a small nose radius, which will increase the heat transfer,” the essay states. (RAND - Speier, Nacouzi, Lee)
Also, most hypersonic weapons need to travel for long periods of time at high speeds, when compared to a re-entry body traveling at hypersonic speed ... therefore … “two of the major parameters in the total heat equation, velocity and time, cannot generally be reduced,” the RAND paper states.
The overall hypersonic weapons evolution, you could call it, is entirely consistent with the Air Force’s long-term hypersonic strategy, which does call for a “stair-step” strategic approach to hypersonics. First, as expected, is hypersonic weapons, an effort that is now on track to emerge in just the next few years. Secondly, a former Air Force Chief Scientist (Dr. Gregory Zacharias) told Warrior in an interview several years ago, the service hopes to engineer hypersonic “drones” for ISR or attack, to be followed by “recoverable drones” over the next several decades. These developments, however, may require many more years of research and technical progress to come to fruition, providing some of the inspiration for some of the current boundary layer scientific work described by Sakulich.
Many Hypersonic weapons are engineered as “kinetic energy” strike weapons, meaning they will not use explosives but rather rely upon sheer speed and the force of impact to destroy targets, developers explain. A super high-speed drone or ISR platform would better enable air vehicles to rapidly enter and exit enemy territory and send back relevant imagery without being detected by enemy radar or shot down.
Interestingly, airflow properties of hypersonic weapons can also provide a window through which to attack or destroy an enemy hypersonic weapon; hypersonic flight is not only complex but also extremely fragile, Ret. Lt. Gen. Trey Obering, Executive Vice President and Directed Energy Lead, Booz Allen Hamilton, told Warrior in an interview. (Obering previously served as the Director of the Pentagon’s Missile Defense Agency)
Therefore, hypersonic weapons could also potentially be stopped by, as Obering put it, causing a “disruption in the airflow.” Changes in aerodynamics can break up forces such as lift, thrust and drag, Obering said.
“These forces are all in balance. When you are going fast there is a small margin in those forces. A disruption can cause the entire vehicle to break up,” he explained.
Essentially, the idea is not to destroy the hypersonic weapon with an explosion, but rather cause an “instantaneous” angle change in the complex, interwoven mixture of air-flow variables. This, quite significantly, can cause an entire vehicle to break apart. A number of things could cause this, such as a laser, rupture of a booster, missile explosion in the vicinity of the weapon in-flight or some other kind of disruption. -- To read Warrior's full report on Defending Hypersonic weapons - CLICK HERE --
“Hypersonics have control surfaces that can maneuver like an aircraft. You would take advantage of the vehicle’s speed and cause a change in vehicle direction,” Obering said.
Booz Allen Hamilton is among several defense industry giants now working on hypersonic weapons technology, including the exploration of emerging methods to defend them.
How can carrier strike groups project power within striking range of enemy targets? How can mechanized armored columns maneuver without being badly crippled by hypersonic attack? How can the most advanced fighter jets maneuver to avoid impact if there simply is no time? Perhaps satellites, ICBMs and defensive weapons such as Ground-Based Interceptors could also be vulnerable? The variables through which hypersonics promise to alter warfare are seemingly limitless. The danger is extremely serious.
“In many ways hypersonics represents the last frontier in aeronautics,” the NASA, AFRL, Case Western Univ. paper states
